| Connection Type: | Y0 | Capacity: | 80KVA |
|---|---|---|---|
| Matieral: | Copper | Weight: | 312KG |
| Dimension: | 405*800*895mm | ||
| Highlight: | medical isolation transformer,outdoor dry type transformer |
||
1-1000KVA Single Phase Dry Type Transformer Variable Transformers 220V / 230V with enclosures
Quick Detail:
Dry Type Transformer
We offer OEM and ODM for This Product.
Input voltage 220V
Output voltage 415V
Description:
Our S(D)G series dry type, iron core Transformers and Reactors adopt high quality low loss silicon sheet and arranged non-bobbin coil winding technology, and we apply vacuum pressure impregnating(VPI) process and solidify baking process to achieve insulation class H or C. Our transformers are widely used on any occasions where voltage is below 1000V and capacity up to 2000KVA, and equipment which require voltage to step up or down. Our Reactors are used in a large variety of applications and in many industrial activities from phase-shifting to harmonic suppression.
Type:
Applications:
Our low voltage transformers are widely used in industrial applications and in commercial and public buildings. They are also used for adjusting the voltage from 690 V to 400 V or as isolation transformers with a voltage ratio of 1:1, providing galvanic separation.
Dedicated products are available for various applications:
- Wind or solar
- Transportation (ie, marine or railways)
- Uninterruptible power supply (UPS)
- Chemical, oil and gas industry
- Motor drive
- Converters
Specifications:
| Number of phases | 3 or 1 |
| Rated power | 1-1000KVA(others on request) |
| Primary/secondary voltage | 220,230,380,400,600,690(others on request) |
| Frequency | 50, 60, 400Hz |
