80KVA 380V 50HZ Electricity Three Phase Voltage Stabilizer Suitable With Split-Phase OEM,Servo AC Stabilizer

Basic Information
Place of Origin: China
Brand Name: Modern
Certification: CE,ISO 9001
Model Number: SBW-30KVA
Minimum Order Quantity: 1
Price: negotiation
Packaging Details: Wooden Packing
Delivery Time: 30 days
Payment Terms: T/T
Supply Ability: 500 unit/month
Detail Information
Rated Capacity (kVA): 80KVA Input Voltage: 260V-450V
Efficiency: >98% Precision: 1%~5%
Dimension: 320X1025X850mm Weight: 112Kg
High Light:

three phase automatic voltage regulator

,

industrial servo voltage stabilizer


Product Description

80KVA 380V 50HZ Electricity Three Phase Voltage Stabilizer Suitable With Split-Phase OEM,Servo AC Stabilizer

Quick details



Capacity:80KVA

The MODERN Power Conditioner is designed to correct power quality problems like brownouts, surge, over-voltage, sags, voltage imbalance, unbalanced current, line noise etc. in the main power supply.



Description:

Owing to our domain expertise and rich industry experience of our professionals, we have been able to design and manufacture a broad range of AC Voltage Stabilizers.



These industry experts fabricate the range making use of extreme quality of raw material that is procured from the authenticated and trusted organizations of the market.



We are Manufacturer which specialized in Servo Voltage Stabilizer, ninterruptible Power Supply (UPS), Active Power Filter, etc for nearly 40 years. And be vendor of Mitsubishi Elevator in East Africa, GE, Emerson.



Voltage Regulator Feature:

1.This series large power voltage stabilizer is an energy-saving new product developed by our company by absorbing the advanced technology of Western Europe.

2.It is provided with two systems of manual/automatic dual control,direct output and stabilizing output, with the functions of over/under-voltage protection,delay and error protection etc, it is reliable and suitable forany load.



Technical parameter
Input current (A): Correlation to the rated capacity
Input voltage (V): 380VAC+/-20% optional, 220VAC+/-20% optional
Output voltage (V): 380VAC+/-5% optional, 220VAC+/-5% optional
Phase number: Three phase single phase
Insulated strength: 2000V/1 Min does not have the puncture
Waveform distortion: ≤ 0.1%
Working frequency (Hz): 50~60
Constant voltage precision: +/-5% adjustable


Since most of textile equipment are installed in cotton-dusty and humid environment and usually voltage regulators are required to be near textile equipment, the voltage regulator of textile equipment designed by our company makes use of the structure of sealing inner air duct board. Auto temperature test control is applied to emit heat. The whole system is moisture proof to ensure continuous and normal operation of equipment in highly humid environment. It has the features of high precision of voltage regulation, good stability and flawless protection.



Input Voltage DBW                          SBW
220±15%,20%,30%,50%    380±15%,20%, 25%30%,50%
Output Voltage (Preset at 1.5%) 220Vac±1-5%                    380Vac±1-5%
Efficiency >98%
Precision 1-5%
Frequency 47-53Hz
Response Time <0.5S/20V(Line Voltage)
Insulated Strength 2000V/1 minute without puncture  2500V/1 minute without puncture
Insulated Resistance >2MΩ
Wave Deformation Nil
Isolation transformer Optional
Surge Protection Optional
